V-type joint bearing assembly WG9725526205

The main function of thrust bearings is to bear the axial thrust of the rotor during operation, ensuring the stable axial position between the turbine rotor and the cylinder. This type of bearing can be used independently or combined with support bearings to form a combined type, known as a joint type. The common structural types of thrust bearings include multi-ribbed type and fan-shaped blade type. Currently, the fan-shaped blade type is widely used.

The structure of the thrust bearing consists of several key components, including the working blades, non-working blades, adjustment gaskets, and the mounting ring. The working blades and non-working blades are installed on the mounting ring. The working blades are responsible for bearing the forward axial thrust of the rotor, while the non-working blades bear the reverse axial thrust. This design ensures that the bearing can efficiently transfer and balance the axial force.

These characteristics of thrust bearings make them play a crucial role in mechanical transmission systems, especially in situations where precise control of the axial position is required. Through optimized design and material selection, thrust bearings can provide reliable performance and a longer service life.

The thrust ball bearing is a type of split bearing. The inner ring, the outer ring, and the cage and the balls can be separated. The inner ring is the sleeve that fits onto the shaft, the outer ring is the sleeve that fits into the bearing housing hole, and there is a gap between them and the shaft.

1. Thrust ball bearings can only withstand axial loads. One-way thrust ball bearings can only withstand axial loads in one direction, while two-way thrust ball bearings can withstand axial loads in both directions.

2. Thrust ball bearings cannot restrict the radial displacement of the shaft, and their maximum rotational speed is very low. One-way thrust ball bearings can restrict the axial displacement of the shaft and the housing in one direction, while two-way bearings can restrict the axial displacement in both directions.

3. Thrust roller bearings are used to bear axial loads mainly, as well as combined axial and radial loads. However, the radial load should not exceed 55% of the axial load. Compared with other thrust roller bearings, this type of bearing has a lower friction coefficient, a higher rotational speed, and a self-aligning property.

4. Thrust cylindrical roller bearings and thrust needle roller bearings are suitable for applications with low rotational speeds. Thrust conical roller bearings have a slightly higher rotational speed than thrust cylindrical roller bearings.
