OE Part Number: 1000428205A (Without A: 1000428205, both are interchangeable)
Brand: WEICHAI Original Factory Repair Parts
Function: Filters metal debris, sludge, and carbon impurities in engine oil, protecting the crankshaft, bearing shells, and camshaft; Built-in bypass valve, when the filter element gets clogged, the engine oil is forced to bypass for supply, avoiding damage to the engine due to lack of oil
Applicable Engines: WP10, WP12, WP13, WD12, Chongqing Third-Generation to Sixth Generation b Weichai Heavy Machinery, heavy truck, construction machinery powertrain
Compatible Vehicles: Shaanxi Auto Delong F3000/X3000/M3000, Shagang Haowuo, Jiefang J6P, Foton Ouman, Beineng, etc. heavy trucks; Loader, construction machinery powertrain of Weichai
Thread: M30×2 (Metric Fine Thread)
• Outer diameter of sealing ring: 92 - 102mm
• Dimensions: Outer diameter Φ108mm, height 228mm
• Net weight per unit: Approximately 1.7 - 2.0kg
• Filtration accuracy: 5μm; Filter material: Composite filter paper; Built-in check valve + bypass valve assembly
• Recommended maintenance cycle: 20,000 - 30,000km (random oil grade, fluctuating working conditions)
One-stop Factory in China
Wichai Original: 612630010239 (Same as the main body, old drawing number)
Industry standard: JX1016 (Common domestic market code)
Brand replacement: LF16285 (Fleegra), W11170/12 (MAN brand), JLX405A (Plain)
FAQ
Q: How to confirm the correct spare part for my truck?
A: Please provide OE number, truck model, engine model and photos of old parts. We will cross‑check for you.
Q: Are your parts original OEM or aftermarket replacement?
A: We supply both original genuine and high‑quality aftermarket replacement parts. Please clarify your requirement before order.
Q: Can I get technical drawing / weight / dimension data?
A:Yes, most items can offer technical data. Please send inquiry with part number
Q: Can I order samples? What is sample lead time?
A: Small trial order is acceptable. MOQ depends on different items. For regular spare parts, 1‑5 pcs is ok.
