Oil Pressure Sensor 20499340

Oil Pressure Sensor 20499340

Oil Pressure Sensor 20499340

Oil Pressure Sensor 20499340

The working principle of the oil pressure sensor is to sense the changes in oil pressure through the internal pressure-sensitive element and convert these changes into electrical signals for output.

The specific working process is as follows: When the engine is running, the pressure measurement device detects the oil pressure and converts the pressure signal into an electrical signal, which is then sent to the signal processing circuit. After voltage amplification and current amplification, the amplified pressure signal is connected to the oil pressure indicator through the signal line. The two coils inside the indicator change the current passing through them in a random manner in response to the changes in oil pressure, thereby indicating the magnitude of the engine oil pressure. At the same time, the amplified pressure signal is also compared with the alarm voltage set in the alarm circuit. When it is lower than the alarm voltage, the alarm circuit outputs an alarm signal and lights up the alarm lamp through the alarm line to alert the driver.

The specific working principle is as follows:

The oil pressure sensor is installed on the main oil passage of the engine. When the engine is running, the pressure measuring device detects the pressure of the engine oil.

The pressure signal is converted into an electrical signal and sent to the signal processing circuit. It undergoes voltage amplification and current amplification.

The amplified pressure signal is connected to the oil pressure indicator through a signal line. By changing the ratio of the currents passing through the two coils inside the oil pressure indicator, the engine's oil pressure can be indicated.

The amplified pressure signal, after voltage amplification and current amplification, is also compared with the alarm voltage set in the alarm circuit. When it is lower than the alarm voltage, the alarm circuit outputs an alarm signal and lights up the alarm lamp through the alarm line.

The oil pressure gauge is an instrument that indicates the oil pressure of the engine's lubrication system. It is used in conjunction with a sensor installed on the main oil passage of the engine's lubrication system. The commonly used oil pressure gauges and sensors are mostly of the electric heating type. The structure of the electric heating oil pressure gauge is the same as that of the electric heating oil quantity gauge, except for the different scale. The shape of the electric heating sensor is a round box, consisting of a diaphragm, heating coil, bimetallic strip, a pair of contacts, a calibration resistor, etc. The sensor fixing hole is connected to the main oil passage of the engine's lubrication system or the oil coarse filter. It works by generating a pulse current due to the deformation of the bimetallic strip, which drives the oil pressure gauge to operate.

• WE guarantee that we will reply your inquiry/email ASAP.
• WE guarantee that you will get higher-quality products from us.
• WE guarantee that Samples will be sent to you at the earliest.
• WE guarantee that you will be served professionally and efficiently.
• WE guarantee that the products will be delivered ASAP.
• WE guarantee that customized requirements will be accepted.

1. 13years experience.

2. Perfect workmanship. Always committed to research and development.

3. Ensure the products meet the quality standards.

4. Ensure the goods will be delivered on time.

5. We will reply you within 24 hours.

6. Provide warm and friendly service and after-sale service.

7. Guaranteed the good quality and best service, as you buy from local supplier.

8. Assorted designs, colors, styles, patterns and sizes are available.

9. Customized specifications are welcome.

Hot Tags: oil pressure sensor 20499340, China oil pressure sensor 20499340 manufacturers, suppliers, factory
